Stainless Steel Button Load Cell
Product Details:
- Material Metal
- Usage Industrial
- Color Silver
- Product Type Button Load Cell
- Click to View more
Stainless Steel Button Load Cell Price And Quantity
- 1 Unit
- 25000 INR/Unit
Stainless Steel Button Load Cell Product Specifications
- Industrial
- Silver
- Button Load Cell
- Metal
Stainless Steel Button Load Cell Trade Information
- Cash Advance (CA)
- 20 Unit Per Month
- 10 Days
- All India
Product Description
We are well-known manufacturer and supplier of wide range of items, here we are exporting Stainless Steel Button Load Cell to our clients that is made with required materials with the assistance of sophisticated technology. This item is perfect choice to use for converting mechanical force into a measurable electrical output. We quality tested this Stainless Steel Button Load Cell on predefined parameters in order to meet set market standards. Register your required units for getting the delivery of the same.
Specification
| Capacity | 450 Ton |
| Compensated Temperature Range | -10 to +40 Deg C |
| Creep Error (30 minutes) | +/-0.04% FS |
| Features | Low profile |
| Ingress Protection | IP65 |
| Input Resistance | 390 +/- 10 Ohm |
| Insulation resistance at 50V DC | >= 1000 M Ohm |
| Material | Stainless Steel |
| Maximum Excitation Voltage | 15V DC |
| Maximum Safe Overload | 150% FS |
| Operating Temperatue Range | -20 to +70 Deg C |
| Output Resistance | 390 +/- 10 Ohm |
| Output Sensitivity(FS) | 2.0 +/- 0.002 mV/V |
| Recommended Excitation Voltage | 5 to 15V DC |
| Temperature Effect on Output | +/-0.005% FS/DegC |
| Temperature Effect on Zero | +/-0.005% FS/DegC |
| Ultimate Safe Overload | 200% FS |
| Zero balance | +/- 1% FS |
