Stainless Steel Compression Load Cell
12000 INR/Unit
Product Details:
X
Stainless Steel Compression Load Cell Price And Quantity
- 12000 INR/Unit
- 1 Unit
Stainless Steel Compression Load Cell Trade Information
- 1000 Unit Per Week
- 7 Days
- All India
Product Description
Specification
|
Application |
Weighbridge |
|
Cable Length |
2-20 meter |
|
Capacity |
10,000 Kg |
|
Compensated Temperature Range |
-10 to +40 Deg C |
|
Creep Error (30 minutes) |
+/- 0.03% FS |
|
Features |
Easy installation |
|
Ingress Protection |
IP68 |
|
Insulation resistance at 50V DC |
>= 1000 M Ohm |
|
Material |
Stainless Steel |
|
Maximum Safe Overload |
150% FS |
|
Output Sensitivity(FS) |
2.0 +/- 0.002 mV/V |
|
Recommended Excitation Voltage |
5 to 15V DC |
|
Temperature Effect on Output |
+/-0.015% FS/DegC |
|
Temperature Effect on Zero |
+/-0.0020% FS/DegC |
|
Zero balance |
+/- 1% FS |
